TransDeco TD600B - Assembly Instructions; Step 1: Install Top Panel; Step 2: Install Bottom Panel; Step 3: Attach Side Panel

- Instqall the bolt(Part A)into the side panel(Part U);
- Insert the camlock into the top panel(Part S);
- Check the “LEFT”mark is on the left side as shown;
- Attach the top panel to the side panel;
- Turn the camlock(Part B)210 degree with
a flathead screw driver(not included).
- Repeat Step 1 to install the bottom panel(Part T);
- Attach Part Y to the back panel(Part W);
- Attach part Z to the back panel;
- Install the connecting bar(Part R) as shown;
* For easy assembly,do not tighten all the screws
until Step 5 completed.
- Install the bolts(Part A) to the side panel(Part V);
- Insert the camlock to the top and the bottom panel;
- Attach the side panel(Part V) to the wood frame;
- Turn the camlocks 210 degree to lock.
