Transition Bicycle Company™ 2023 | transitionbikes.com | (360) 366-4960 | info@transitionbikes.com
QUICK START GUIDE:
Installing Your Battery
Removing Your Battery
Installing Your Battery Door
1. With the handle of the battery facing outwards,
insert the bottom of the battery into the frame of the
bike.
2. Swing the top of the battery into the bike, lining up
the metal plate with the slot on the back side of the
battery.
3. Press the battery into the frame until you hear an
audible “Click.”
Tip: With your hand, move the battery back and forth in
the frame to make sure that it is secure. If you did not
hear an audible click, remove the battery and try again.
1. Remove the battery door by turning the dial to the
horizontal position and sliding the door up and
forward.
2. Hold on to the battery with one hand.
3. Using the other hand press the rubber push button
in the handle, as much as you can, to release the
battery.
4. Keep holding the button while gently pulling down
on the battery.
5. Remove the battery by swinging the top portion
down and forward.
Before installing the battery door, ensure the battery is
securely installed in the bike.
1. Make sure the door dial is in the horizontal position
and positioned towards the front of the bike.
2. Slide the bottom of the door into the bike so that the
bottom tab is secure in the frame.
3. Swing the top of the door up against the frame.
4. While holding the door against the frame, turn the
door dial either clockwise or counterclockwise into
the vertical position.
Tip:
• Make sure the battery door is secure by lightly pulling
down on the door. If the door is not secure, attempt
again or rotate the dial 180 degrees to ensure that the
internal stopper is correctly lined up.
• Some doors were misprinted and the circular indent
marks may not line up. Rotate the dial 180 degrees to
the vertical position and ensure the door is secure
before riding.
“CLICK”
2.
1.
Hold and Press
Button to Release
2.
3.
LOCKED
UNLOCKED
ROTATE
180°
ROTATE
180°
