Extension Cord Support
For safety and comfort, this lawn mower is
equipped with a support to direct extension cord
to the opposite of safety lever.
To use this support, the operator must fully
unwind the extension cord, plug the machine in
and do as follows:
Fold the extension cord and pass through the
opening of the support (1). Then loop around
hook (2), leaving a loose fit between support and
safety lever (3).
Removing Cutting Blade -
Models MC / SL / TS / KM / CG / RS
Turn off and unplug lawn mower from power
source. Using tool furnished by TRAPP (7)
(except MC 50/60E), loosen screw (6) from the
axle of the motor (8) that holds the blade (5) and
flange (4). Replace cutting blade.
Replacing Cutting Blade
Remove side screws (1), and cover (2).
Using one hand firmly hold fan of the motor (3).
