Instructions Before Operating the Shredder
Checking:
Before operating the shredder check:
If there are tools or objects on the motor or on the
equipment, mainly inside the grain funnel or in the
green crop feeder.
If there is something obstructing the motor.
If the rotation direction is correct.
If the voltage of the power source is the same of that
of the shredder.
If there are no people or object close to the belt
pulleys or in the direction of the material to be
shredded. Keep people and children in a radius of
30 m far from the equipment.
If the shredder cover is properly closed.
If the counter cutting blade is properly set and
tightened (pg. 59).
Note: if the equipment is properly prepared, start the
motor, allow it to reach maximum revolution and start
working.
Belt Tensioner Start - TRF 300G
1
Image merely illustrative.
The motor must be operated only if the belt tensioner's lever (1) is in the relief position, i.e., without tensioning
the belt as indicated in the image above, then, in this position turn the motor on and after it reaches its
maximum rotation, move the belt tensioner's lever in the direction as indicated in the image below moving
the motor on the mounting base and verifying if the belts will be tensioned. The belt tensioner's lever can
only be tensioned when the motor is in full operation, do not turn the motor off with the tensioner activated,
this harms the motor and makes the gasoline powered engine difcult to start.
