Traulsen TBC13 - Specifications, Data, and Installation; Product Specifications and Operating Data; Refrigeration System Installation Guide

DATA TBC5 TBC13 TBC1H TBC1HR TBC2H TBC2HR
Single or Dual System Single Dual Dual Dual Dual Dual
Remote Chill Compressor n/a No Yes Yes Yes(2) Yes(2)
H.P.
1
1 1/2 1/2 1/2 1/2(2) 1/2(2)
BTU/HR
1
4300 2820 2820 2820 2820(2) 2820(2)
H.P.
2
n/a 1-1/4 4 4 4(2) 4(2)
BTU/HR
2
n/a 5710 18,700 18,700 18,700(2) 18,700(2)
Refrigerant Type R-404A R-404A R-404A R-404A R-404A R-404A
Refrigerant Charge oz. 29 31 25 25 25(2) 25(2)
Refrigerant Charge
2
n/a 45 See Note
3
See Note
3
See Note
3
See Note
3
Condenser RLA
1
11.7 5.1 10.5 10.5 10.5(2) 10.5(2)
Condenser RLA
2
n/a 9.3 See Note
3
See Note
3
See Note
3
See Note
3
Unit Voltage 115 208/115 115 115 115(2) 115(2)
Phase 1 1 1 1 1 1
Hz 60 60 60 60 60 60
Full Load Amps 13.3 13.4 14.9 14.9 14.9(2) 14.9(2)
NEMA Plug Type 5-20 14-20 Hard Wire Hard Wire Hard Wire Hard Wire
III. SPECIFICATIONS/OPERATING DATA/INSTALLATION
1= Self-Contained Holding or Primary Compressor.
2= Blast Chilling or Secondary Compressor.
3= Varies with remote system.
-3-
DIMENSIONS TBC5 TBC13 TBC1H TBC1HR TBC2H TBC2HR
Length - Overall in. 54 41 48-1/2 48-1/2 48-1/2 48-1/2
Depth - Overall in. 34-7/16 34-1/2 37-5/8 41-1/4 71-5/6 75-1/4
Height - Overall in. 34 74 90-3/8 90-3/8 90-3/8 90-3/8
Capacity 12 x 20 Pans 10 26 1 Rack 1 Rack 2 Racks 2 Racks
Capacity 18 x 26 Pans 5 13 1 Rack 1 Rack 2 Racks 2 Racks
Capacity Product Weight 100 lbs. 200 lbs. 300 lbs. 300 lbs. 600 lbs. 600 lbs.
III. a - PRODUCT SPECIFICATIONS:
III. b - OPERATING DATA:
III. c - REFRIGERATION SYSTEM INSTALLATION:
All Traulsen blast chillers, with the exception of model TBC5, require
the use of a oor drain or oor mounted condensate evaporator for
condensate removal. Refer to Section IV. h of the blast chill owner’s
manual for more information.
Remote refrigeration installation requirements apply only to models
TBC1H/TBC1HR and TBC2H/TBC2HR. A remote condensing unit, op-
erating on R-404A refrigerant, is required for Blast Chill operation on
these models. The remote condensing unit(s) should be capable of
providing 18,700 BTU/hr @ -10°F evaporator temperature and 90°F
ambient.
Air-cooled and water-cooled remote condensing units are available
from Traulsen as an optional accessory. Please note that these
should be adequate for any installation within a 25 foot radius from
the cabinet. Beyond this distance, the actual capacity of the remote
condensing unit and line sizing may change depending upon the
length and layout of the connecting piping from the remote condens-
ing unit to the Blast Chiller. These utilize a 1/2” liquid and 1-1/8”
suction lines. Proper specication of the remote condensing unit
needed and line sizing should be dened by a qualied refrigeration
engineer or technician, based on the jobsite installation needs.
The low pressure cut-out of the remote condensing unit should be
adjusted to obtain an evaporator coil temperature NO LOWER THAN
-15°F. If the length of the connecting piping is 40 feet or less, the
condensing unit low pressure cut-out settings will be approximately
15 +/- 2 PSIG cut-out and 25+/- 3 PSIG cut-in.
For more information please contact the factory.
