introduction
Thank you for purchasing the Traxxas TRX-4M™ with the Ford F-150
Body. This ocially licensed model gets the full Traxxas treatment
with unsurpassed realism, including molded front grill, door handles,
and side mirrors. The design of the TRX-4M oers a new way to
experience all the fun, adventure, and scale realism of the TRX-4 in
a 1/18 platform. Oil-lled shocks control body motion and provide
smooth suspension travel over any terrain. Steel frame rails and a
smooth running drivetrain give it true outdoor capability over rocks
and through grass and streams. The tight turning radius and precise
throttle control give it fantastic indoor maneuverability. Your new RC
model oers the highest level of innovation, performance, and quality
that is the hallmark of all Traxxas vehicles.
This manual contains the instructions you will need to operate and
maintain your model so that you can enjoy it for years to come. We
want you to feel condent that you own one of the best-performing
models in the market and that it is backed by a team of professionals
who aim to provide the highest level of factory support possible.
Traxxas models are about experiencing total performance and
satisfaction, not just with your model, but also with the company that
stands behind it.
We know you’re excited about getting your new model on the trail,
but it’s very important that you take some time to read through the
Owner’s Manual. This manual contains all the necessary setup and
operating procedures that allow you to unlock the performance
and potential that Traxxas engineers designed into your model.
Even if you are an experienced RC enthusiast, it’s important to
read and follow the procedures in this manual.
Thank you again for going with Traxxas. We work hard every day
to assure you the highest level of customer satisfaction possible.
We truly want you to enjoy your new model!
Traxxas Support
Traxxas support is with you every step of the
way. Refer to the next page to nd out how to
contact us and what your support options are.
Quick Start
This manual is designed with a Quick
Start path that outlines the necessary
procedures to get your model up
and running in the shortest time possible. If you are an
experienced RC enthusiast, you will nd it helpful and fast.
Be sure and read through the rest of the manual to learn
about important safety, maintenance, and adjustment
procedures. Turn to page 10 to begin.
REGISTERING YOUR MODEL
In order to serve you better as our customer, please
register your product within 10 days of your purchase
online at Traxxas.com/register.
Traxxas.com/register
FCC Compliance
This device contains a module that complies with the limits for a Class B digital device as described in part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The limits for a Class B digital device are designed to provide reasonable protection against harmful interference in residential settings. This product generates, uses and can radiate radio
frequency energy, and, if not operated in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The user is cautioned that changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Canada, Industry Canada (IC)
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the
following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device.
Radio Frequency (RF) Exposure Statement
This equipment complies with radio frequency exposure limits set forth by FCC and Industry Canada for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the radiator and your body or bystanders and must not be co-located or operating in conjunction with any other
antenna or transmitter.
