Traynor Keymaster K4 - Technical Specifications; Amplifier Performance Specifications; Input and Control Specifications; Output, Indicators, and Protection

4
Specifications
Type
Keyboard Amplifer
Cabinet Program Power (Watts)
300
Speaker Configuration - LF (Size / Power)
12-inch/200-watts
Speaker Configuration - HF (Size / Power)
2x4.5-inch/50-watts / 2x2.5-inch/50-watts
Frequency Response (Hz +/-3dB)
20 - 20k
Input Channels
4
Channel 1 - inputs
2 Stereo pairs of 1/4-inch TRS
Channel 1 - controls
Gain, 3 band EQ, 5 position voicing, Lead/OD Trim
Channel 1 - switches
Lead/Overdrive, Tube/Solid State input select
Channel 2 - inputs
Stereo pair 1/4-inch TRS, mono XLR
Channel 2 - controls
Gain, 3 band EQ
Channel 3 - inputs
Stereo pair of 1/4-inch TRS, stereo RCA
Channel 3 - controls
Gain
Channel 4 - inputs
Stereo pair of balanced 1/4-inch TRS
Channel 4 - controls
Gain
Master Volume Control
Yes
Input Sensitivity (mV)
Ch.1/2 - 500mV / Ch. 3 - 250mV
Line Out (type / configuration)
Stereo XLR (Post EQ, Pre Master), Ground Lift
Line Out Sensitivity (Vrms)
1Vrms
LED Indicators
Power, Clip Lead/OD
Protection
Thermal
Headphone Jack
Yes (Rear)
Other Features
Unfilitered mono-summed Subwoofer 1/4-inch output
Dimensions (DWH, inches)
15.5 / 23.3 / 19.6
Dimensions (DWH, cm)
39.4 / 59 / 50
Weight (lbs / kg)
50 / 22.7
