Traynor YS1003 - Page 6

4
Electronics
 Vacuum Tubes 2xEL34(alt6CA7types)
  3x12AX7(alt7025A)
  DCpoweredfilamentsupplyonpreamptubes
 Bias Supply Autobalancing
 Power Output 50WattsRMS
 Speaker YCV50:12inchCelestion®speaker
 Channels onelead&onecleanchannel
 Input Impedance 1Megohm
 Tone Controls Separatetonecontrolsonbothchannels
  (Treble,Bass,&Middle)    
  MasterVolumeandReverbonMasterSection
 Reverb Accutronics®long-reverbwithdual-springs
 Power Supply Fullyregulated
Connectors
 Input Jack 1/4inchphonejack
 Send Jack Balanced1/4inchTRS
  (Tip-positive/Ring-negative/Sleeve-ground)
 Return Jack Unbalanced1/4inchphonejack,10kohms
 Speaker Jacks Two1/4inchphonejacks
 Footswitch Jack 1/4inchTRS,acceptsastandard,
  latchingdual-footswitch&connectingcable
Cabinet
 Cabinet Construction allplywood
 Covering Leatherette
 Grille Perforated18-gaugepaintedsteel
  withclothcovering
 Dimensions (WxHxD) 23.0inchx18.5inchx9.0inch
  58.4x46.9x22.8cm
 Weight 45lbs(20.4kg)
Power Requirements
 120V 60Hz1.0A
 230V 50Hz0,5A
Warranty Two-year, unlimited (even if you break it!)
transferable warranty*
 (valid in USA and Canada only)
 Footswitch Included Twobutton(ChannelSelect/Boost)
  withseparateLEDindicators
Specifications
External Speaker Jack/s
20
Theseunder-the-chassismounted1/4inchjacksallowconvenientconnectionofan
8-ohmexternalspeakercabinet.Ifyoudisconnecttheinternal12inchCelestion®
speaker,youcanconnectuptotwo8-ohmexternalcabinets.
Replacement Tube Selection & Bias
TheYCV50BcomesequippedwithEL34outputtubes.Replacementscanbeanybrand
ofEL34or6CA7andwerecommendthatthebiasvoltagebemeasuredandpossibly
adjusted(seebelow).Swappingin6L6/5881outputtubesrequiresachangeinoneofthe
biasresistorstoavoidtubeoverheating.Themodificationshouldbeperformedbyaqualified
technician.
**The YCV50B has test points and a bias adjustment pot. If you have installed new EL34/6CA7s
and wish to check and possibly adjust bias, we recommend adjusting the zero signal bias to +75
mV +/-10mV DC at each of the test points.
