TREELINE FDRP600AS - Page 5

2 nd
1 st
4
Step 3
Attach upper legs to bottom of
hopper using sixteen M6 x 15 mm
bolts and M6 washers.
Then secure upper legs to leg
brackets using four M8 x 60 mm
bolts, M8 washers and M8 nuts.
Step 4
Attach lower legs to ends of upper
legs using eight M8 x 60 mm
bolts, M8 washers and M8 nuts.
Carefully set feeder upright.
