Trek Fetch+ 4 - Page 10

2023 Fetch+ 4
7
Steering Dr ivetrain Routing Battery Headsets Frame Accessor ies
Drivetrain: belt tensioner
7
9
10
11
1
4
7Nm
2
2
3
3
5
6
8
12
5Nm
12
5Nm
1
Belt roller
5291300
2
Washers (M8)
3
Bearings
4
Bolt (M8x40mm)
5
Bolt socket set screw — W5282014
6
Tensioner arm
5280807
7
Tensioning bolt (M8x100mm)
8
Bolt (M6x60mm)
9
Tensioning nut (upper)
10
Tensioning nut (lower)
11
Coupling nut
12
Bolts (M6x10mm)
