Trek Procaliber 6 - Brake and Shift Cable Routing

2024 Procaliber Alloy
3
Brake and shi routing


Shift housing
1. Housing exits the downtube.
2. Slide the foam sleeve over the housing.
3. Route the housing and foam sleeve up the downtube.
1
2
3
Rear brake hose
1. Thread the rear brake hose through the foam
sleeve.
2. Route the hose and foam sleeve up the downtube.
1
Foam sleeves — W528082
2
Rear brake hose
3
Shift housing

Zip ties
