-30-
Router Table for the Craftsman
APPENDIX
Plan for
HITACHI TR12
Router
4 holes for
M5 M/C
screws
21mm
21mm
77mm
77mm
77mm
21mm
21mm
77mm
FRONT OF CRT TABLE
Position of
Router Handle
Position of
Router Handle
C
C
