-35-
Router Table for the Craftsman
Plan showing gasket
required for
Bosch POF52, 400A,
500A & 600 ACE
2 through holes
8mm diameter
60mm Ø
approx.
100mm
MATERIAL MIN. 3.2mm (1/8") THICK
C
approx.
145mm
75mm
