2
3. Hardware Installation
ŸThe TI-G80 can be placed on a desktop, wall, or mounted to a DIN-rail.
1. Attach the DIN-rail mount bracket to the switch.
2. Position the switch in front of the DIN-rail and hook the mount bracket over
the top of the rail.
Mounting the switch Releasing the switch
DIN-rail Mounting Instructions
3. Rotate the switch downward towards the rail to lock it into place. You will
know it is secure when you hear the click.
4. To remove the switch, pull down to clear the bottom of the DIN-rail and
rotate away from the rail.
