TRENT CaterSense V2 User Manual

CaterSense the Intelligent answer
CS-INSTV2-0.01 Page 12 01-15
Model: CaterSense V2
b) Setpoint allocation and set-up
The CaterSense V2 has two 270° turn pots called R113 and R114 (as shown
below). These pots are used to allocate different setpoints dependent on the DIL (DIP) switch.
R114
R113
POTS Sensor Inputs
MODE
DIL (DIP)
position
R113 setpoint R114 Setpoint Sensor 1 Sensor 2 Sensor 3 Sensor 4
1 N/A
Supply
Temperature
N/A
Supply
Temp sensor
N/A N/A
2 N/A
Supply
Temperature
Gas pressure
sensor
Supply
Temp sensor
N/A N/A
3 N/A
Supply
Temperature
N/A
Supply
Temp sensor
N/A N/A
4 N/A
Supply
Temperature
Supply Temp
sensor
CO2 sensor N/A N/A
5 N/A
Supply
Temperature
Gas pressure
sensor
Supply
Temp sensor
N/A N/A
6 N/A
Supply
Temperature
Supply Temp
sensor
CO2 sensor N/A N/A
7 N/A
Supply
Temperature
Gas pressure
sensor
CO2 sensor
Supply
Temp sensor
N/A
8 N/A
Supply
Temperature
Gas pressure
sensor
CO2 sensor
Supply
Temp sensor
N/A
9
Demand
Temperature
Supply
Temperature
Supply Temp
sensor
Demand
Temp sensor
N/A N/A
10
Demand
Temperature
Supply
Temperature
Gas pressure
sensor
Supply
Temp sensor
Demand
Temp sensor
N/A
11
Demand
Temperature
Supply
Temperature
Supply Temp
sensor
CO2 sensor
Demand
Temp sensor
N/A
12
Demand
Temperature
Supply
Temperature
Gas pressure
sensor
CO2 sensor
Supply
Temp sensor
Demand
Temp sensor
