TRENT CaterSense V2 User Manual

CaterSense the Intelligent answer
CS-INSTV2-0.01 Page 5 01-15
Model: CaterSense V2
1.02 Fixing details
1.02A For standard control unit:
The CaterSense V2 unit has six (6) mounting holes which can be used (as shown below)
Note: Ensure that the enclosure is mounted on a clean and level surface away from the direct cooking
area or wet surfaces.
1.02B For inbuilt speed control unit:
The CaterSense V2 + ATSC unit has four (4) mounting holes which can be used (see
Diagram 2)
Note: Ensure that the enclosure is mounted on a clean and level surface away from the direct cooking
area or sinks and other wet areas.
223
248
92.5
235
111.5
53
48
Diagram 2: Fixing details
168
230
244
BOTTOM
TOP
200
270
48
