Trevi CMP 588 DAB User Manual

16
CMP 588 DAB
USB INPUT
PLAYBACK
1. Connect a USB device to the USB input (10);
2. Select the USB source. The "USB" will appear on the display;
3. After a few seconds the LCD display will show the number of tracks on the disc. Playback will start
automatically.
NOTE: Refer to the CD-MP3 PLAYER OPERATION paragraph for the rest of the functions.
AUX INPUT
REPRODUCTION
1. Connect an external device to the AUX IN input (9);
2. Select the AUX source. The "ENTER AUX" will appear on the display;
3. Start playback of the external device. For all playback functions refer to the manual of the external device.
HEADPHONE
1. Insert the headphones into the headphone jack (4);
2. Start the desired playback and adjust the volume.
TECHNICAL FEATURES
GENERAL
Power and consumption: .................................................................. 100-240V 50/60 Hz
4 x "C" batteries (UM2) not included
FM band reception: ...........................................................................87.5 - 108 MHz
DAB/DAB+ band reception: .............................................................. 174 - 240 MHz
Bluetooth transmission power: .........................................................2.5mW
Bluetooth transmission band: ...........................................................2.4GHz
Dimensions: ......................................................................................211x 233x 118mm
Remote control battery: .....................................................................CR2025
PRECAUTIONS FOR CORRECT DISPOSAL OF THE PRODUCT.
The symbol shown on the equipment indicates that waste must be disposed of in “separate collection” and so the
product must not be disposed of together with urban waste.
The user must take the product to special “separate waste collection centres” provided by local government, or deliver
it to the retailer against the purchase of a new product.
Separate collection of waste and subsequent treatment, recycling and disposal operations promotes the production of
equipment with recycled materials and limits negative effects on the environment and on health caused by improper
handling of waste.
Illegal disposal of the product leads to the enforcement of administrative penalties.
ENGLISH

Trevi CMP 588 DAB Specifications

General

Tuner type	Analog
FM band range	87.5 - 10 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	30
Disc loading type	Top
Optical drive type	Player
Disc types supported	CD, CD-RW
Display type	LCD
Backlight color	Blue
Built-in display	Yes
Control type	Buttons, Rotary
Product color	Black
Volume control	Rotary
RMS rated power	- W
Number of built-in speakers	2
Cassette deck	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Apple docking compatibility	-
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Compatible battery sizes	C, UM-2
Number of batteries supported	4
Package type	Box
Package depth	140 mm
Package width	380 mm
Package height	250 mm
Audio formats supported	MP3
Warranty period	- year(s)

Weight and Dimensions

Depth	130 mm
Width	280 mm
Height	240 mm
Weight	1275 g
