Trianco Activair - TECHNICAL DETAILS; Model Specifications

32
Technical Details
Model Activair HT 9kW Activair HT 15kW Activair HT 22kW
Power Supply
/
230V~/50Hz 230V~/50Hz 230V~/50Hz
Moisture Resistance IPX IPX4 IPX4 IPX4
Electrical Shockproof
I I I I
Heating Condition - Ambient Temp. (DB/WB): 7/6°C, Water Temp. (In/Out): 30/35°C
Heating Capacity Range kW 3.10~8.90 5.40~14.95 8.00~22.00
Heating Power Input
Range
kW 0.65~2.10 1.05~3.85 1.60~6.90
Heating Current Input
Range
A
2.9~9.2 4.6~16.9 7.0~30.3
Cooling Condition - Ambient Temp. (DB/WB): 35/24°C, Water Temp. (In/Out): 12/7°C
Cooling Capacity Range kW 1.20~5.72 3.60~10.50 4.20~15.00
Cooling Power Input
Range
kW 0.65~2.40 1.12~4.47 1.80~7.30
Heating Current Input
Range
A
2.9~10.5 4.9~19.6 7.9~32.1
Hot Water Condition - Ambient Temp. (DB/WB): 20/15°C, Water Temp. (In/Out): 15/55°C
Hot Water Capacity
Range
kW 3.92~10.68 6.50~18.50 10.00~27.00
Hot Water Power Input
Range
kW 0.78~2.47 1.27~4.65 1.90~7.10
Hot Water Current Input
Range
A
3.4~10.8 5.6~20.4 8.3~31.2
Max. Power Input kW 3.0 5.3
9
Max. Current Input
A
13.5 24.5 39
Water Flow m
3
/h 1.0 1.7 2.9
Refrigerant / Proper Input kg R290 /0.50kg R290 / 0.85kg R290 / 1.30kg
CO
2
Equivalent Ton 0.0015 0.0026 0.0039
Sound Pressure (1m) dB(A) 42 43 47
Sound Power Level
(EN12102)
dB 57 57 62
Net Weight kg 80 160 202
Operation Pressure
(Low Side)
MPa 0.8 0.8 0.8
Operation Pressure
(High Side)
MPa 3.0 3.0 3.0
Unit Dimension(L/W/H) mm 1167×407×795 1287×458×928 1250×540×1330
Shipping mm 1300×485×940 1420×540×1080 1380×570×1480
Dimension(L/W/H)
Compressor Brand HIGHLY HIGHLY HIGHLY
Circulation Pump Y/N
Y Y Y
Operating Ambient
Temperature
℃
-25~43 -25~43 -25~43
Fan Quantity
/ 1 1 2
Fan Motor Type
/
DC motor DC motor DC motor
Fan Motor Power Input
(min~max)
W
55~105 60~120 60~160
Fan Speed (RPM) RPM 300~600 220~600 300~750
Water Connection (inch) inch
1 1 1
Water Pressure Drop
(max)
kPa 40 20 65
Circulation Pump Head
m
7.5 7.5 12.5
Cabinet Type
Galvanized sheet+
ASA
Galvanized sheet+
ASA
Galvanized sheet+
ASA
