4
GET
MORE
HELP:
Connections
For more detailed installation guidance please visit our website :
http://www.TRIAX.dk/montage
On the website you will also nd instructions for the correct installation of the
F-connector, IEC connector and an antenna socket. We recommend you download
these instructions as required
A
F-connector mounting instruction
B
IEC-connector mounting instruction
C
TRIAX TD-outlets mounting instruction
1. Input
2. Outputs (self-terminating)
3. Mains lead
4. Power pack
5. Tilt/Slope (0 - 6 or 12 dB) - basic conguration 0 dB
6. Signal gain regulation (0 - 6 or 12 dB) - basic conguration 6 dB
Mounting instruction
TRIAX IFA 284/288
distribution ampliers
A
B C
EN
