Triax MOD103T - Page 5

RF status
RF on/off
User selectable
RF level adjustment
0…-30dB (65dBuV…95dBuV)
Encoder settings
Audio type
User selectable AAC / MPEG
Video bit rate
User selectable 2, 4, 6, 8, 10, 12 Mbit (default)
Service settings
Service name
User editable (TV program name)
Service ID
User editable from 1…65535
Channel settings
Channel
User selectable RF output channel (preset UK channel plan)
LCN
User editable 1…999
(Logical Channel Number)
Stream settings
OrgNetwork ID
User editable from 1…65535
Network ID
TS ID
Network name
User editable
Parameter settings
Constellation
QPSK, 16QAM, 64QAM
Video bitrate
2, 4, 6, 8, 10, 12 Mbit
Code rate (FEC)
1/2, 2/3, 3/4, 5/6, 7/8
Guard interval
1/4, 1/8, 1/16, 1/32
Tranmission mode
2K / 8K FFT
Bandwidth
6, 7, 8 MHz
Password settings
Old password
Enter old password
New password
Enter new password
Confirm new password
Enter new password again
Other settings
Language
User selectable EN, FR
