Triax MOD103T - Specifications; Source input; RF output; Compression

Specifications
MOD103T Specifications
Source input
Input channel
1
video
HDMI 1.4
Video system
480i/576i/720p/1080i/p
Audio
HDMI
RF output
Type
1 multiplex DVB-T with a digital service
Frequency
177…858 MHz
MER
30dB Min.
Output level
95dBµV (max)
RF Level adjustment
1dB per step
Attenuation step
0…30dB
Compression
Video
H.264 baseline profile level 4.0
Video resolution
1080p 25/30 max
Video bit rate
12 Mbps. Max
Audio
MPEG-2 / AAC
Audio bit rate
192 Kbits/s
DVB insertion tables
SDT, NIT
Editable field
Service Name, Provider Name, Service ID,
LCN, NIT Version, TS ID, Network name,
Network ID, Original Network ID, Country
Connections
HDMI IN
HDMI IN
HDMI OUT
HDMI pass through
RF output
2 RF outputs (one providing accessory
power supply 9 Volts DC for IR pass)
DC switch
Power supply 9 Volts DC for IR pass
RF INPUT
RF combiner (with LTE filter)
USB
Firmware upgrade
IR OUT
IR emitter output
General
Modulation
Standard DVB-T (ETSI EN 300 744)
Constellation : QPSK, 16QAM, 64QAM
Guard interval : 1/4, 1/8, 1/16, 1/32
Code rate : 1/2, 2/3, 3/4, 5/6, 7/8
FFT Carrier Mode : 2K, 8K
Bandwidth : 6MHz, 7MHz, 8MHz
Power supply
12 VDC
Display
LCD panel, 2x16 characters
Dimensions
220 x x106 x 32mm
Environmental for
operating
Temperature: 5°C - 40°C
Relative humidity : 80%@30°C
