TECH-SUPPORT@TRICKSTUFF.DE SERVICE MANUAL – DIRETTISSIMA/MAXIMA PUMP V2024_02. PAGE 17 OF 27
Assembly of the brake pump
Note: The reservoir cap is slightly bent for equal preload of the sealing reservoir membrane (see
image below).
1. First put the reservoir cap on a new membrane. The surrounding seal lip should show no
damages and equal distance all around. Now put the reservoir cap on the pump housing, as
shown in the image below.
Note (MAXIMA): Now is the time to put the correct MAXIMA-Cap on the left/right pump
housing, left and right reservoir cap differ in logo orientation! Regularly, the logo faces away
from the rider.
