Trico DR-7 - Specification and Operating Parameters

Page 5 of 28
3. Specification and Operating Parameters
Physical Specifications
Length (Front to Back):
9.00 in.
22.8 cm
Width (Side to Side):
12.00 in.
30.5 cm
Height:
19.75 in.
50.2 cm
Weight (Instrument Only):
13 lbs.
5.9 kg
Power
Voltage:
100-240V AC
Frequency:
50/60 Hz
Amperage:
1A
Instrument contains a 1A power fuse located at the power plug inlet
Hardware
Operating system:
Windows 10 IoT
Memory:
64 GB Flash
External USB Ports:
2 x USB “A”
Ethernet Connection:
RJ45 cat 5
RAM:
4 GB DDR2 RAM
Processor:
Intel® Celeron® CPU N2807 @ 1.58 Ghz
Environmental Conditions
For indoor use on a solid level surface without movement or vibration.
Use in a well-ventilated area.
Room temperature:
50ºF to 85ºF
10ºC to 29ºC
Humidity:
5% to 50% non-condensing
CAUTION: DO NOT operate the DR-7 with the back panel removed. Unplug the DR-7 from the power
supply before removing the back panel for adjustments. Check with Trico before removing as this could
void the unit warranty. All other repairs must be done at the factory
.
