Trident 78 Owners Manual5
Trident 78 Input Channel Group Assignment
1-2 Group Assignment
Assigns the Channel post-fader
signal to the Group 1 and 2 mix
buses through the Channel Pan
Control. With the Channel Pan
control in mid position, the signal
will be fed to Group 1 and 2 in
equal amounts. If the Channel
Pan Control is positioned fully
anti-clockwise (left) the channel
signal will only feed Group 1 and
when positioned fully clockwise
(right), the signal will only feed
Group 2.
5-6 Group Assignment
Assigns the Channel post-fader
signal to Group 5 and 6 mix buses
through the Channel Pan Control.
Operation is the same as the 1-2
Group assignment.
L-R Mix
Assigns the Channel post-fader
signal to the Left and Right mix
buses through the Channel Pan
Control. Operation is the same as
the 1-2 Group assignment.
Sometimes referenced as the Main
mix or Remix bus assignment. In
a multi-track studio environment,
this L-R Mix assignment and the
Channel Monitor Input allow the
user to have two separate external
inputs (Channel Mic/Line and
Monitor return) that can be sent
to the Left and Right mix busses,
eectively doubling your inputs
on mixdown (Remix)
3-4 Group Assignment
Assigns the Channel post-fader
signal to Group 3 and 4 mix buses
through the Channel Pan Control.
Operation is the same as the 1-2
Group assignment.
7-8 Group Assignment
Assigns the Channel post-fader
signal to Group 7 and 8 mix buses
through the Channel Pan Control.
Operation is the same as the 1-2
Group assignment.
