Trident 88 Owners Manual6
Trident 88 Input Channel Mic/Line Options
Trident 88 Input Channel Group Assignment
1-2 Group Assignment
Assigns the channel post-fader
signal to the Group 1 and 2 mix
buses through the channel Pan
control. With the channel Pan
control in mid position, the sig-
nal will be fed to Group 1 and 2
in equal amounts. If the channel
Pan Control is positioned fully
anti-clockwise (left) the channel
signal will only feed Group 1 and
when positioned fully clockwise
(right), the signal will only feed
Group 2.
5-6 Group Assignment
Assigns the Channel post-fader
signal to Group 5 and 6 mix buses
through the channel Pan control.
Operation is the same as the 1-2
Group assignment.
L-R Mix
Assigns the channel post-fader
signal to the Left and Right mix
buses through the channel Pan
control. Operation is the same
as the 1-2 Group assignment.
Sometimes referenced as the Main
Mix or Remix bus assignment.
In a multi-track studio environ-
ment, this Left and Right mix as-
signment and the channel Mon-
itor Input allow the user to have
two separate external inputs
(channel Mic/Line and Monitor
Return) that can be sent to the
Left and Right mix busses, ef-
fectively doubling your inputs
on mixdown (Remix).
3-4 Group Assignment
Assigns the channel post-fader
signal to Group 3 and 4 mix buses
through the channel Pan Control.
Operation is the same as the 1-2
Group assignment.
7-8 Group Assignment
Assigns the channel post-fader
signal to Group 7 and 8 mix buses
through the channel Pan control.
Operation is the same as the 1-2
Group assignment.
