Trigger 4 PLUS - Page 3

1
Trigger Pedestal Mount Assembly Instructions
Part Number 2020
If running 12 volt power to the Pedestal, insert the 12 volt power
wire included in the original Trigger 6 Shooter packaging (not
included with Pedestal Kit). Wire is inserted on one side of the
base, then routed through opening as shown.
NOTE: Skip this step if not using 12 volt power to base or if using
the 4 Channel Triggers.
2
Halves are then screwed
together with wire inserted.
Use the 2.6 mm pan head
screws.
Plastic parts
Hardware
A
A
B
B
C
D
E
F
3mm x 13mm Flat head (x2)
2.8 x 10 mm
Pan screw (x4)
2.6 mm
Pan screw (x2)
Flat washer (x2)
PLEASE READ ALL INSTRUCTIONS AND CHECK TO BE SURE ALL PARTS LISTED
ARE INCLUDED BEFORE BEGINNING ASSEMBLY.
12 volt power cable
not included
VHB
