Trimax Snake - Replace Bearing Race; Bearing Race Installation Accuracy

5
When only replacing the Bearings and
reusing the old Hub, then the Bearing
Race should be replaced at the same
time.
Bearing Kit (416-860-470)
Remove the old Bearing Race in the
Wheel Hub from both ends.
This can be done by knocking the
Bearing Race out from the opposite
end it is positioned.
It is recommended to use a bearing
press or a local engineering shop to
press the Bearing Race into the hub.
If you have access to this tooling use
a drift as shown to locate the Bearing
Race.
IMPORTANT:
Bearing Race must be sitting square
to the Hub when pressed in place.
