Trimble EZ-Guide 250 User Manual

Increase value / up to next option Proceed to next screen
Decrease value / down to next option Accept settings
In setup screens, the icons match the buttons beside them.
Function buttons (on the left)
Beside each function button, there is an icon. When you press the function button, you select the feature that is
shown on the icon.
ITEM DESCRIPTION
1 Coverage logging icon
2 Middle function button
The following function icons may appear beside the buttons on the left of the screen:
ICON DESCRIPTION ICON DESCRIPTION
Display information tab window Cancel changes
Turn on coverage logging Go up one menu level
Turn off coverage logging Return to guidance screen
Zoom in Move back one screen
Zoom out Display Help
6

Trimble EZ-Guide 250 Specifications

General

Display Size	4.3 inch
Update Rate	5 Hz
GNSS Support	GPS
Receiver Type	GPS
Guidance Modes	AB Line, Pivot
Operating System	Proprietary
Guidance Accuracy	6-8 inches with ব্যভার করা correction
Accuracy	6-8 inches pass-to-pass (with ব্যভার করা correction)
