EZ-Guide 500 System Cabling Guide 39

Connecting to an EZ-Steer System 4

H EZ-Boom controller – 4 Laptop connector (for

firmware upgrade)

–

I EZ-Steer controller – 5 “S1” connector –

J EZ-Steer motor 53058-00 6 Alternate power

connector

–

K EZ-Steer motor cable 62257 7 “P3“connector –

L EZ-Steer extension cable 62974 8 “P1“connector –

M EZ-Boom cable 61437 9 “S3“connector –

N Power tap to PDL radio 63185 10 To power –

O Power cable 62817

Item Description Part number Item Description Part number

Trimble EZ-Guide 500 - Page 41
