B Data Formats
144 Trimble M3 Total Station User Guide
Sideshot records
Stakeout records
F1/F2 records
time 24-hour time stamp
code Feature code
SS ,pt,ht,sd ,ha,va,time,code
SS Sideshot record identifier (fixed text)
pt Point number
ht Height of target
sd Slope distance
ha Horizontal angle
va Vertical angle
time 24-hour time stamp
code Feature code
SO , pt , (sopt) , ht , sd , ha , va , time ,
SO Stakeout record identifier (fixed text)
pt Recorded point number
(sopt) (Original number of point staked)
ht Height of target
sd Slope distance
ha Horizontal angle
va Vertical angle
time 24-hour time stamp
face,pt,ht,sd ,ha,va,time
face One of the following:
F1 Shot taken using Face-1 (fixed text)
F2 Shot taken using Face-2 (fixed text)
pt Point number
ht Height of target
sd Slope distance
ha Horizontal angle
va Vertical angle
time 24-hour time stamp
