Trimble M3 Total Station User Guide 151
Specifications C
C.23Battery pack BC-65
Note – Tested at 25 °C (normal temperature). Operation times may vary depending on the
condition and deterioration of the battery.
C.24Environmental performance
C.25Dimensions
C.26Weight
Output voltage 7.2 V DC rechargeable
Continuous operation time
Continuous distance/angle measurement 8 hours
Distance/angle measurement every 30 seconds 16 hours
Continuous angle measurement 30 hours
Operating temperature range –20 °C through +50 °C
(–4 °F through +122 °F)
Storage temperature range –25 °C through +60 °C
(–13 °F through +140 °F)
Main unit 168 mm W × 173 mm D × 347 mm H
(6.6 inch W x 6.8 inch D x 13.7 inch H)
Carrying case 470 mm W × 350 mm D × 231 mm H
(18.5 inch W x 13.8 inch D x 9.1 inch H)
Main unit 5.0 kg (11.02 lbs), approx. (including tribrach)
Battery BC-65 0.4 kg (0.88 lbs), approx.
Carrying case 3.2 kg (7.05 lbs), approx.
Charger 0.3 kg (0.66 lbs), approx.
