Trimble M3 Total Station User Guide 13

Overview of the Trimble M3 Total Station 2

Figure 2.3 Trimble M3 total station – Face-2

Horizontal axis

indication mark

Optical plummet

Tribrach

The laser safety

label shown is

telescope

attached to the

Objective

LASER LIGHT

IS EMITTED

FROM THIS PART

Data output /

external power

input connector

WARNING

Input voltage

7.2 - 11 V DC

Leveling screw

Circular level
