TrimbleR10ReceiverWebHelp
PowerSupply ReceiverConnection
DCPowerInputVoltagelimits 8Vto32V
Absolutemaximuminputvoltage 32V
Overvoltage 21Vto32V
Workingvoltage 10Vto21V
Undervoltagecharging <10V
Sumofchargetimeforallbatteries 5to6hours
Chargerinfirsthour >60%
Chargingthebattery
CautionEnsurethatnothingobstructstheventsinthebackandbottomofthecharger.
Thebatteryissuppliedpartiallycharged.Chargethebatterycompletelybeforeusingitforth efirst
time.
Tochargethebattery,useonlyachargerthatTrimblerecommendsforch argingtheLithium
ionbattery.
Iftheequipmenthasbeenstoredforlongerthansixmonths,chargethebatterybefore
using
theR10receiver.
Thechargeroperatesbetween0C(32F)and40C(104F).Chargingabatteryattemperaturesin
therangeof0C(32F)to5C(41F)willtakelongerthanchargingatroomtemperature.
Tochargethebattery:
1. Ensurethat
theventsinthebackandbottomofthechargerareunobstructed.
2. Placethechargeronahard,flatandlevelsurface,toensurethatthereisairflowunderthe
charger.
3. Toapplypowertothecharger,usetheACtoDCconverteror12Vcigaretteplug.The
charger
scanstheslotsforabattery.
4. Placethebatteryinanyoftheslots.Theredlightturnsoff(cantakeupto5s).Foran
explanationoftheLED,seeLEDStatusIndicator.
5. Chargingtakesapproximately3hoursperbatteryatroomtemperature.Ifseveralbatteries
arecharginginthebatterycharger,thebatterieswillbechargedsequentially,fromleftto
right.
Leaveadeeplydischargedorshortedbatteryovernightinthechargertoattempttorevivethe
battery.Ashortedbatteryistypicallyrevivedassoonastheslotisscanned.IftheredLEDturns
off,
thebatteryisrevived.IftheredLEDstayson,thebatteryisnolongerfunctionalandneedsto be
replaced.
LEDstatusindicator
BesideeachslotaretwoLEDindicators(RedandGreen)todisplaythebatterystatus:
