TrimbleR10ReceiverWebHelp
Batterycharger
ThechargercanchargetwotypesofLithiumionbatteries.Itcanbepoweredbymainsorvehicle
battery.Thefollowingfigureshowsthebattery,dualslotbatterycharger(P/N53018010),power
supply(P/N78650)andACpowercable(P/N78651):
TheChargerKitDual
Slotconsistsof:
Chargerdualbatteryslot
Powersupplyforcharger
CableACkitACforpowersupply
Chargeablebatteries
Thechargecanchargethefollowingtypesofbatteries:
LithiumionRechargeableBatt ery(SmartBatt ery),4.4Ah,11.1V,PartNo 49400
iIonRechargeableBattery,2.4Ah,7.4V,PartNo54344
Chargerslots
Thechargerhastwoslots.Eachslotcanchargereithertypeofabattery.Batteriesarecharged
sequentially.BesideeachslotaretwoLEDindicators(redandgreen)toindicatethebatterystatus.
Powersupply
Thechargercanbepoweredbymains(usingthepowersupplyforthecharger)orbycarvoltage
(12V,usingaCableCartoDualSlotCharger).
Mainspower
Mainspowersupplyisanexternaladapterworldwideuseable.Differentcordsfordifferent
countriesaresuppliedwithadapter(CableKitACforPowerSupply).
Vehiclepower
Thechargercanbepoweredbyvehiclevoltageofnominal12V.Itcanwithstandvoltagesofa
vehiclevoltageofnominal24V(maximum32V).Soiftheuserconnectsthevehiclecableby
mistaketoa24Vsocketinavehiclethechargerdoesnotstartcharging
butlatchesinfault
conditionandflashesallgreenLEDs.Thepowermustberemovedtoresetthefaultcondition.
Technicaldata
PowerSupply ReceiverConnection
ACInputVoltage 100to240VAC+/10%
ACFrequency 50to60Hz
DCOutputVoltage 19V
DCOutputcurrentcharger Approx.3.5A
DCPowerInputVoltageoperation 10Vto21V
Unitswitchoffifvoltageisoutofrange
