SendRawWAASData–SelectthisboxtooutputtherawdataextractedfromtheSBASsatellites.
BINEX
ThefollowingfieldsappearwhenyouselectBINEXfromthelistatthetopofthepage.
ObservableRate–Selecttheoutputratefortherawobservables.

SmoothPseudorange–EnablePseudorangesmoothing.
SmoothPhase–EnablePhasesmoothing.
GSOF
ThefollowingfieldsappearwhenyouselectGSOF(GeneralSurveyOutputFormat)messagefrom
thelistatthetopofthepage.
GSOFMessages–SelectwhichGSOFmessageswillbeoutputonthisport.
OmniSTAR
DATA
forOmniSTAR–EnablesthedemodulatedOmniSTARdataoutputonthisport.Thisoutput
canthenbeusedasanExternalOmniSTARinputonanon‐TrimbleOmniSTAR‐capablereceiverthat
hasavalidandappropriateOmniSTARsubscription.
DATAforTrimble–EnablesthedemodulatedOmniSTARdataoutputonthisport.
Thisoutputis
thesamerawdataasabovewithaTRIMCOMMwrapper(0xC4)tosupportuseasanExternal
OmniSTARinputonanTrimblereceiver.ThereceivermusthaveavalidandappropriateOmniSTAR
subscription.
DEBUG–Enables/DisablesDEBUGOmniSTARoutputonthisport.
Bluetoothmenu
BluetoothInfo
ModuleInfo–ThisisthemodeloftheBluetoothmoduleusedinthereceiver.
StackVersion–ThestackversionistheTrimblefirmwareversionoftheBluetoothmoduleusedin
thereceiver.
LocalName–ThenameofthedevicethatappearswhenitisdiscoveredbyanotherBluetooth
‐
enableddevice.MadeupoftheReceiverModelname,Serialnumber,andSystemName.See
IdentityInformation
.
BluetoothMACAddress–TheBluetoothMAC(MediaAccessCont rol)addressoftheBluetooth
moduleusedinthereceiver.
Discoverable–SetthisfieldtoTrueorFalse.WhenthisfieldissettoTrue,thereceiverwillbe
shownwhenitisdiscoveredbyanotherBluetooth‐enableddevice.If
thisfieldissettoFalse,the
receiverisnotshowninthediscoverylist.
PinCode–ThepasswordthatisrequiredtopairthereceiverwithanotherBluetooth‐enabled
device.
