TrimbleR10ReceiverWebHelp

OmniSTARSubscriptionInformation

Thispageprovidesinformationaboutth eOmniSTARsubscription.

IfthereceiverisconnectedtoanOmniSTAR‐capableantennawithOmniSTARreception,OmniSTAR

subscriptionscanbeactivatedremotely.

HP/XPorVBSExpirationDateUTC–ShowswhenthecurrentOmniSTARsubscriptionswillexpire.

Thereceiversdonotshipwithanactivesubscription.

ContactOmnistarforasubscription

activation.

HP/XPEngineMode–Whenthereceiverhasavalidsubscription,theenginemodeindicateswhich

servicesareavailable.

HP/XPorVBSFirmwareVersion–DisplaysthecurrentversionofOmniSTARfirmwarethatis

loadedinthereceiver.

SerialNumber–A10‐digit

number,forexample,1010012017.

{b}Note–{/b}WhenorderingasubscriptionfromOmniSTAR,youmustrefertothisserial

number.Pleasedonotsendtheserialnumber(forexample,5221F12345)oftheactualreceiver.

OmniSTARStatus

UsethispagetomonitorthestatusoftheOmniSTARsatellite,subscriptions,andsolution.

OmniSTARConfiguration

ProvidesthecurrentOmniSTARconfigurationsettings.

ExternalDataMode–ThemodesettingsetintheOmniSTARConfiguration

page.

 Don'tUse–OmniSTARoff.

 Auto–OmniSTARautotrackingmode.WhenanHPorXPsolutionisavailable,outputanHPor

XPsolution.WhenanHPorXPsolutionisnotavailablebutaVBSsolutionisavailable,output

VBSsolution.

 HP+G2‐OmniSTARHP

andG2mode.

 G2Only‐OmniSTARG2mode.

 HP+XP‐OmniSTARHPandXPmode.

 HPOnly–OmniSTARHPonlymode.

 XPOnly–OmniSTARXPonlymode.

 VBSOnly–OmniSTARVBSonlymode.

InternalDataMode–ThemodesettingsetintheOmniSTAR

Configurationpage.

 Off–OmniSTARoff.

 Auto–OmniSTARautotrackingmode.WhenanHPorXPsolutionisavailab le,outputanHPor

XPsolution.WhenanHPorXPsolutionisnotavailable,butaVBSsolutionisavailable,output

VBSsolution.

 HP+G2–OmniSTARHP

andG2mode.
