TrimbleR10ReceiverWebHelp

HP/XPLibraryStatus

ProvidesinformationrelatingtotheHP/XPLibrary(softwaresuppliedbyOmniSTARusedtodecode

andprocesstheOmniSTARsignal).AlsoreferredtoastheOmniSTAREngine.

InternalLibrary–ThecurrentstatusoftheHP/XPLibrary.ItcanbeActiveorNotActive.

Engine

–Themodeusedbythelibrary.ItcanbeHP,XP,G2,HP+G2,HP+XP,orUnknown.

SubscriptionStart/Expiry–OmniSTARHP/XPsubscriptionstartandexpirydates.OmniSTAR

servicescan notbeusedwithoutavalidOmniSTARsubscriptionfortheappropriateservice.

SubscribedEngine–TheOmniSTARsubscribedservicecurrentlyinusebytheOmniSTARlibrary.

HorizontalPrecision[m]–Auser‐definedhorizontal3‐sigmaprecisiontoleranceforthereceiver,

whichisalsousedtodeterminewhentheOmniSTARsolutionhasconverged.Toeditthisvalue,go

toReceiverConfiguration/Masks.

VerticalPrecision[m]–auser‐definedvertical3‐sigmaprecisiontoleranceforthereceiver,which

isalsousedtodeterminewhentheOmniSTARsolutionhasconverged.To editthisvalue,goto

ReceiverConfiguration/Masks.

ReceiverMotion–Thecurrentmotionsettingfor

thereceiver.ItcanbeKinematic(Moving)or

Static.OmniSTARinitializationtimecanbereducedbycorrectlysettingthereceivermotion.To

changethissetting,gotoReceiverConfiguration/AdvancedSettings.

OmniSTARMotion–ThemotionoftheGNSSantennaasdeterminedbytheOmniSTARLibrary.It

canbe

Static,Kinematic(Moving),orUnknown.

SeedwithLastknownPos–Ifenabled,theLastKnownpositionstoredinthereceiverwhenitwas

lastturnedoffisusedtoseedtheOmniSTARLibrary.Seedingisamethodofspeedingupthe

initializationprocessbytellingtheOmniSTARLibrarythelocation

oftheGNSSantenna.TheLast

KnownPositionfunctioncanbeusedwhenavehicle‐mountedsystemisparkedovernightandis

powereddownandpoweredupwithoutthevehiclehavingmoved.(Thisfunctioncanonlybe

configuredbyapplicationsoftware.)

SeedwithFixedRTKPos–Ifenabled,and

ifthereceiverisinKinematicmodeandcomputingvalid

FixedRTKpositions,theOmniSTARLibraryiscontinuallyseededwithFixedRTKpositions.IfinStatic

mode,theOmniSTARlibraryisseededwiththefirstcomputedFixedRTKpositiononly.This

functionenablestheOmniSTARHP/XPLibrarytocontinuetoprovide

aprecisepositioningsolution

forshortperiodswhenanRTKsolutionisnotavailablebecauseofaradiodrop‐outorother

interference.Toenablethisfeature,gotoOmniSTAR/Configuration

.

SeedQuality–

 Unknown– Thereisnoseedavailable.ThereceiverdoesnothaveanSBASorOmniSTARVBS

position.

 Valid,sourceunknown–Thereisavalidseedavailablebutthesourceisunknown.

 Invalid,lowconfidencelevel–Whenusingthelastknownposition

forseeding,ifthelast

knownpositionfromtheprevioussessionhasalowconfidencelevel,itwillberejected.One

ofthecausesoflowconfidencelevelisahighvelocityassociatedwiththeposition,suggesting

thattherec e iverwasmovingwhenitwaspowereddown.
