Trimble R10 - Wi-Fi LED

TrimbleR10ReceiverWebHelp
Radiomode Radio
LEDAmber
Description
transmittingcorrections

Wi‐FiLED

Receivermode Wi‐FiLEDAmber
Wi‐Fioff Off
Wi‐FiisAccessPoint(Basemode/sendingcorrections) Mediumflash
Wi‐Fiisclient(andnotconnectedtoanAccessPoint) Off
Wi‐Fiasclient(Rovermodereceivingcorrections) Veryslowflash

BatteryLED

Receivermode PowerLEDGreen Description
Off Off
On.Healthypower On Eitherinternalbatteryorexternalpower
Lowpower Fastflash(<about15%power)
Loggingdatainternally Flashesoffeverythreeseconds

Lemoport
WhenyouloadfirmwareusingtheWinFlashutility,theLEDsshowas:

Button/LED Appears
 On
 Off

SeetheSatelliteLEDsectionabove.
 Off

