Trimble R10 User Manual

TrimbleR10ReceiverWebHelp
Action Power
button
Description
Cleartheephemeris
fileandresetthe
smartantennatothe
factorydefaults
Holdfor15
seconds
TheRadio,Wi‐Fi,andSatelliteLEDsturnoffafter2seconds.The
batteryLEDremainson.After15seconds,theSatelliteLEDcomes
ontoindicatethatitistimetoreleasethe
Powerbutton.
Deleteapplication
files
Holdfor30
seconds
TheRadio,Wi‐Fi,andSatelliteLEDsturnoffafter2seconds.The
batteryLEDremainson.After15seconds,theSatelliteLEDcomes
onandstaysonfor15seconds,thenturnsofftoindicatethatitis
timetoreleasethe
Powerbutton.ThebatteryLEDthenremains
onfor15secondsafterreleasingthePowerbutton.Thesmart
antennathenrestarts.

Note–Theterm“press”meanstopressthebuttonandreleaseitimmediately.Theterm“hold”
meanstopressthebuttonandholditdownforthegiventime.
SatelliteLED

Receivermode SatelliteLEDAmber
Nosatellitesor<1satellitetracked Off
BootuporinMonitormode On
Tracking<4SVs Fastflash
Tracking>4SVs Slowflash

RadioLED

Radiomode Radio
LEDAmber
Description
Noreceiveor
transmit
Off

Receive Radioslowflash
Seethetableatthetopofthistopic.
ThisLEDalsoflasheswhenusingtheWi‐Fionlyforreceiving
corrections.
Transmit Radioslowflash
Seethetableatthetopofthistopic.
ThisLEDalsoflasheswhenusingtheWi‐Fionlyfor

Trimble R10 Specifications

General

Channels	440
RTK Horizontal Accuracy	8 mm + 1 ppm RMS
RTK Vertical Accuracy	15 mm + 1 ppm RMS
Operating Temperature	-40 °C to +65 °C
L1 C/A Code	Yes
L2E	Yes
L2C	Yes
L5	Yes
Beacon	No
FM Radio	No
WAAS	Yes
MSAS	Yes
EGNOS	Yes
Storage Temperature	-40 °C to +75 °C
Ingress Protection	IP67
Positioning Accuracy (Static) - Horizontal	3 mm + 0.5 ppm RMS
Positioning Accuracy (Static) - Vertical	5 mm + 0.5 ppm RMS
Signal Tracking	BeiDou
RTK Initialization	< 8 seconds
Battery Life	Up to 7 hours
SBAS Accuracy	50 cm
Glonass Code	L1 C/A, L2 C/A
Communications	Bluetooth
