TrimbleR10ReceiverWebHelp
10. Double‐clicktheicontoconnect.
Creatinganewconnection
1. FromyourWindowsControlPanel,openNetworkConnectionsandthenclickCreateanew
connection:

2. TheNewConnectionwizardstarts.Usethefollowingsettingsto:
 Setupanadvancedconnection
 Connect
directlytoanothercomputer
 Connectasa Guest

3. GivetheconnectionanamethatrelatestotheCOMportusedontheofficecomputer.Thisis
likeacableconnectionbetweentwocomputers,butthecableisreplacedbyaBluetooth
wirelessconnection.TapNext.Thefollowing
dialogappears:

4. SelectthecorrectCOMportfromthelistandthentapNext:

ThedefaultsfortheSPSModularreceiverare:
 Username:admin
 Password:password
5. ThenewDirectconnectionappearsintheNetworkConnectionsfolder.Ifthatstatusshowsas
Connected,youcancontinue
tothewebinterface.

6. Right‐clickontheconnectionandthenselectStatus:

7. TheDetailstabshowstheServerIPaddress.UsethisIPtoconnecttothereceiverusingthe
webinterface.

{b}Tip–{/b}TogetthePPPaddressfromthefrontpanelof
thereceiver,press from
theHomescreen.
