7. IntheDial‐upphonenumberfield,enterauniquenameornumber.Thisexampleshowsthe
nameBERT.Toenableotheruserstousethisconnection,selecttheAllowotherpeopletouse
thisconnectioncheckbox.ClickConnect.

Windowsautomaticallystartstestingthe
Internetconnection.ClickSkip.ThemessageThe
Internet connectivity test was unsuccessfulappears:

8. SelecttheSetuptheconnectionanywayoption.ThemessageThe connection to the
Internet is ready to useappears:

9. ClickClose.
{b}Note–{/b}ClickingCloseonthepagedoesnotaffecttheabilitytoconnecttotheInternet
ortheGNSSreceiverweb
interface.
10. BackattheNetworkandSharingCenter,selecttheManagenetworkconnectionslink:

TheNetworkConnectionsscreenappears:

11. Selectandright‐clickonthenewdial‐upconnectionandthenselectRename:

12. RenamethedeviceusingauniqueidentifierandthenpressEnter
13. Double
‐clickthenewdial‐upconnection.
14. SelectProperties.
15. SelecttheNetworkingtabandthenclickProperties.

16. ClickAdvanced:

17. CleartheUseDefaultgatewayonremotenetworkcheckboxandthenclickOK:

18. ClickOK:

19. ClickOK.

20. Beforecreating
thePPPconnection,aBluetoothconnectionisrequired.CreateaBluetooth
connectionbetweenthecomputerandthereceiver,forexample,Copperhead).IntheSystem
tray,double‐clicktheBluetoothManagericon
:

