6. Assign“MyLocation”auniquename.Thisenablesyoutomanageanumberofdifferent
deviceswithoutconfusion.ClickEdit:

7. EnterauniqueLocationnametomatchtheBluetoothconnectionnameandthenclickOK.
8. SelecttheModemstab.
9. ClickAdd.

10. EnsurethatyouselecttheDon'tdetectmymodemcheckboxandthenclickNext:

11. EventhoughyouarecreatingaBluetoothconnection,selecttheCommunicationscable
betweentwocomputersoptionandthenclickNext.

12. SelecttheappropriateCOMportforyourdevice.SelectCOM40,
thedefaultCOMPortsetting
fromtheearlierBluetoothpairing(Section1,step6
above),andthenclickNext:

13. ClickFinish.

14. Verifythatthecreationofthenewmodemdeviceiscorrect.Checkthatitisattachedto
COM40.ClickOK.

TheBluetoothpairingandhardwaresetuparenowcomplete.
Section3‐CreatinganInternetconnection
1. Clickthe
WindowsStartbuttonandthenselectControlPanel.
2. ClicktheNetworkandInternetlink.
3. ClicktheNetworkandSharingCenterlink:

{b}Note–{/b}Iftherenowirelessconnectionsorwirelessnetworksareavailable,thefollowing
screenappears:

4. SelecttheConnecttoanetworkoption.
5.
SelecttheSetupaconnectionornetworklink:

6. SelecttheSetupadial‐upconnectionoptionandthenclickNext:


Trimble R10 Specifications

General

Channels	440
RTK Horizontal Accuracy	8 mm + 1 ppm RMS
RTK Vertical Accuracy	15 mm + 1 ppm RMS
Operating Temperature	-40 °C to +65 °C
L1 C/A Code	Yes
L2E	Yes
L2C	Yes
L5	Yes
Beacon	No
FM Radio	No
WAAS	Yes
MSAS	Yes
EGNOS	Yes
Storage Temperature	-40 °C to +75 °C
Ingress Protection	IP67
Positioning Accuracy (Static) - Horizontal	3 mm + 0.5 ppm RMS
Positioning Accuracy (Static) - Vertical	5 mm + 0.5 ppm RMS
Signal Tracking	BeiDou
RTK Initialization	< 8 seconds
Battery Life	Up to 7 hours
SBAS Accuracy	50 cm
Glonass Code	L1 C/A, L2 C/A
Communications	Bluetooth
