Trimble R10 User Manual

TrimbleR10ReceiverWebHelp

4. IntheBluetoothdevicelist,locateandselecttheBluetoothdevice,forexample,R8‐3,
4906165381:Trimble)andthenclickNext:

Waitwhiletheconnectionisestablished...

5. SelectSerialPortCOM3andthenclickNext.

{b}Note–{/b}Ifthereceiverreports
BluetoothDial‐UpNetworking,donotselectitorthe
SerialPortCOM4_RESERVEDservice.TrimblerecommendsthatyouselectCOM3.
WindowsassignsadefaultCOMport,forexample,COM40.

6. EnsuretheUsedefaultCOMportcheckboxisselectedandwritedowntheCOMportname
forfuture
reference(Section2,step12below)andthenclickNext:

7. Ifrequired,renametheBluetoothconnectionnameandthenclickNext:

8. ClickFinish:

9. ABluetoothconnec tionbetweenthereceiverandthecomputerisnotyetrequired;this
connectionisrequiredinSection3,step21
.ClickClosetoclosetheBluetoothSettingsdialog:

Section2‐Settingupandconfiguringthemodem
1. ClicktheWindowsStartbuttonandthenselectControlPanel.
2. ClicktheHardwareandSoundlink:

3. ClickthePhoneandModemOptionslink:

4. Enteranareacode.Any
numberexcept800issuitable.Nootherinformationisrequired;that
is,carriercodeoroutsidelinefieldscanbeleftblank.
{b}Note–{/b}ClickingOKwithoutanareacodebringsupanerror.Youmustentersometype
ofareacodeorcitycode,nomatterwhichcountry/region
youchoose.ClickOKtoclosethe
message.

5. ClickOK.Anewmodemlocationiscreated.Inthisexample,itisMyLocation:

Trimble R10 Specifications

General

Channels	440
RTK Horizontal Accuracy	8 mm + 1 ppm RMS
RTK Vertical Accuracy	15 mm + 1 ppm RMS
Operating Temperature	-40 °C to +65 °C
L1 C/A Code	Yes
L2E	Yes
L2C	Yes
L5	Yes
Beacon	No
FM Radio	No
WAAS	Yes
MSAS	Yes
EGNOS	Yes
Storage Temperature	-40 °C to +75 °C
Ingress Protection	IP67
Positioning Accuracy (Static) - Horizontal	3 mm + 0.5 ppm RMS
Positioning Accuracy (Static) - Vertical	5 mm + 0.5 ppm RMS
Signal Tracking	BeiDou
RTK Initialization	< 8 seconds
Battery Life	Up to 7 hours
SBAS Accuracy	50 cm
Glonass Code	L1 C/A, L2 C/A
Communications	Bluetooth
