Trimble R10 - Section 1 - Creating a Bluetooth connection between the computer and the receiver

TrimbleR10ReceiverWebHelp
runningontheWindows7operatingsystem.Thecomputermustbeconnectedtothereceiverin
oneofthefollowingways:
 Peer‐to‐peerusingEthernetcross‐overcableorBluetoothwirelesstechnology
 ThroughaLocalAreaNetwork(LAN)
 ThroughtheInternet
Seealso
Changingthereceiversettingsusingthewebinterface.
Connectingtothereceiverusingawebbrowser
1. EntertheIPaddressofyourreceiverintotheaddressbarofthewebbrowserasshown:

2. Ifsecurityisenabledonthereceiver,thewebbrowserpromptsyoutoenterausernameand
password:

Thedefaultloginvalues
forthereceiverare:
 UserName:admin
 Password:password
Ifyoucannotconnecttothereceiver,thepasswordfortheadminaccountmayhavebeenchanged,
oradifferentaccountmaybeinuse.Contactyourreceiveradministratorfortheappropriatelogin
information.
Steps
Thestepsrequiredare:
1. CreateaBluetoothconnectionbetweenthecomputerandthereceiver.
2. Setupandconfigurethemodemhardware
.
3. CreateaNetwork/InternetconnectiontoaccesstheTrimblereceiverthroughawebbrowser
.
{b}Note–{/b}TheseinstructionscanalsobeusedtoconnecttoaSNB900radio‐modem.
Section1‐CreatingaBluetoothconnectionbetweenthecomputerandthereceiver
1. Inthesystemtray(inthelowerrightcorneroftheWindowstaskbar),clicktheUparrowand
thenclicktheBluetoothicon.Fromtheshortcutmenuthatappears,selectAddaDevice:

2. Windows7searchesfortheBluetoothdevice.Ensurethatitisswitchedon.Matchthemodel
andserialnumbertotheoneshownonthescreen.Selectthecorrectdeviceandthenclick
Next:

3. Select
theEnterthedevice'spairingcodeoption:

