4. Bydefault,the pairingcodeis0000.EnteritinthedialogandthenclickNext:

5. Afterthedevicehasbeensuccessfullyaddedyouneedtoinspectitsproperties.Clickonthe
DevicesandPrinterslinkinthesuccesswindow:

Alternatively,selectShowBluetooth
DevicesfromtheBluetoothcontextmenu:

6. IntheBluetoothDevicewindow,right‐clickthedeviceandthenselectPropertiesfromthe
shortcutmenu:

7. IntheServicestab,clearthecheckboxesforCOM1andCOM2services.Takenoteofthelocal
COMportforCOM3(thisis
COM11intheexamplebelow).YouwillneedtoknowthisCOM
portforSection2,step7
:

Section2‐Settingupandconfiguringthemodem
1. ReturntotheControlPanelandusethesearchfieldinthetoprightcornertosearchfor
"phone".

2. SelectPhoneandModem:

3. SelecttheModemstab:

4. ClickAdd.Thefollowingwizardappears:

5.
SelecttheDon'tdetectmymodem;IwillselectitfromalistcheckboxandthenclickNext.
WaitaminutewhiletheWindows7operatingsystempopulatesthelist:

6. FromtheModelslist,selecttheCommunicationscablebetweentwocomputersoptionand
thenclickNext.
{b}Note
–{/b}EventhoughyouareusingaBluetoothconnectionyouareeffectivelyusingitas
a"cable"betweenthedevices.
Thefollowingdialogappears:

7. TheCOMportyounotedearlier(Section1,step7
)shouldbedisplayedbelowSelectedports.
ClicktheporttoselectitandthenclickNext.
8. WaitwhileWindows7installsthemodem.
