Thisgeoidalheightwillagreewithlocalheightdatumsmoreaccurately.Itispossibletouploada
subgriddedgeoidmodelfileratheraglobalgeoidmodelfile.Aglobalgeoidmodelfileistoolarge
toloadintoreceivers,soyouneedtoreduceitssizeto
lessthan1Kb.
1. UsetheTrimbleBusinessCentersoftware‐HeavyConstructionEditiontosubgridthefile.It
producesa*.ggffile,whichyoumustrenametoa*.sgdfile.
2. ImportitintoanapplicationfileintheConfigurationToolBoxutility.
3. UsetheConfigurationToolBoxutilityto
selectthecoordinatesystemtouploadthe*.sgdfile.
4. UsetheConfigurationToolBoxutilitytoloadthatfiledirectly,ifyourcomputerisconnectedto
thereceiver.Otherwise,importtheapplicationfileusingthewebinterface(selectReceiver
Configuration/ApplicationFiles
).
 Inmanycasestheinclinedplanemethodisusedasitisofteneasiertogetthisfromasite
calibration.Iffourormorecontrolpointsarewelldistributedaroundthesite,thentheSCS900
sitecalibrationprocessgivestheoptiontofitaninclinedplanetomap
theGPSellipsoidal
heightstolocaldatumheights.Toimporttherelevantfile,seeOutputtinglocalsiteormap
projectioncoordinates(NEE).
Onceitisloadedintothereceiver,thereceivercanthenoutputtheelevationvalues.Forexample,
theNMEAGGAmessagewillnowoutputgeoidalheights.
Outputtinglocalsiteormapprojectioncoordinates(NEE)
IfyourequireNorth,East,Elevation(NEE)outputfromthereceiver,youmusteither:
 UsetheConfigurationToolBoxutility(CoordinateSystemmenu)toselectamapprojectionor
asitecalibrationandthencreateanapplicationfile(*.cfg)andloadthatintothereceiver.You
canuseConfigurationToolBox
utilitytoloadthefiledirectlyifyourcomputerisconnectedto
thereceiver,otherwiseyoucanimporttheapplicationfileusingthewebinterface(select
ReceiverConfiguration/ApplicationFile
).
 UseaTrimblecalibrationfile(*.dc,or*.cal)createdbytheSCS900software,theTrimble
BusinessCentersoftware,oraTrimbleutility.Uploadthefileusingthewebinterface(select
ReceiverConfiguration/ApplicationFiles
.FromtheOperationlist,selecttheUpload&Apply
ProjectionandCalibrationfileoption.)
Oncetherequiredfileisloadedonthereceiver,thereceivercanoutputthemapprojectionorsite
coordinatesNorth,Easting,Elevationvalues.Forexample,theNMEAPJKmessageoutputsNEEifa
validDCor
Projectionfileisloaded.
Outputtingprecisionsitecoordinates(NEE)andpreciseorthometricheights
Outputtingnortheastelevation(NEE)siteormapprojectioncoordinates
Dooneofthefollowing:
 UsetheConfigurationToolboxutilitytoselectacoordinatesystemfromthedatabase.Create
theapplicationfile(*.cfg),andthendooneofthefollowing:
1. Loadtheapplicationfileintothereceiverusingthe
ConfigurationToolboxutility.
