2. Usingthereceiverwebinterface,selectReceiverConfiguration/ApplicationFiles
.Click
UploadandthenclickStartNow.
 AfterasitecalibrationisperformedwiththeSCS900software,uploadthatinformation
directlyintothereceiver:
1. Loadthe*.dcorthe*.calfileintoyourcomputer.
2. Usingthereceiverwebinterface,selectReceiverConfiguration/ApplicationFiles
.Click
UploadandthenclickApplyProjectionandCalibrationfile.
Ifaninclinedplaneisinthesitecalibration,thenheights(GHT)areavailablethatarebasedonthe
inclinedplane.
Outputtingelevationsbasedonageoid
ThereceivercomputesellipsoidalheightsthatareconvertedbytheSCS900software
intolocal
elevationsusingtheinclinedplanemethodorageoid.
Ifyourequirethereceivertooutputelevationsforanotherapplicationintermsofthegeoid
(orthometricheights),thenthedefaultgeoidmodelinthereceiverisnotaccurateenoughfor
precisepositioning.
Toloadanduseaprecisegeoid
model:
 Thereceiverneed4.12firmwareorlater.
 Thefilesizeoftheusergeoidfileneedstobe1Kborsmaller.Thefilemusthaveasuffixof
.sgd.
UsingtheConfigurationTo olboxutility,clickSelectandthenselectacoordinatesystem:
1. SelectApplyGeoid
GridtoloadtheGeoidSubGridfile(*.sgd).
2. CreatetheApplicationfile(*.cfg)anduploadittothereceiverusingConfigurationToolboxor
thereceiverwebinterface.
3. Usingthereceiverwebinterface,selectReceiverConfiguration/ApplicationFiles.
4. ClickUploadandthenclickStartNow.
{b}Note–
{/b}Tocreateageoidfilethatislessthan1Kbinfilesize,useoneofthefollowing
programs:
TrimbleSiteVisionOfficetotrimthegeoidfiledownto thissize.
TrimbleGridFactorytostorethesubgriddedgeoidfilewiththe.sgdfileextensionratherthan
the
.ggffileextension.
TrimbleGeomaticOfficeandTrimbleBusinessCenter‐HeavyConstructionEditionsoftwarealso
enablesthecreationofsub‐gridsofgeoidmodels.Inthiscase,itisnecessarytosetupaprojectthat
referencesthefullgeoidmodelsothatsub‐gridsofitcanbeexported.

Supportedfiletypes
Thefollowingtableshowsthefiletypesthatyoucantransfertoorfromthereceiver,andthe
softwareorutilitythatyoumustusetotransfereachfiletype.

