Trimble R10 - Adding frequencies for the 450 MHz internal radio using the WinFlash utility

TrimbleR10ReceiverWebHelp
Toupgradethefirmware
1. StarttheWinFlashutility.TheDeviceConfigurationscreenappears.
2. FromtheDevicetypelist,selectthereceiver.
3. FromthePCserialportfield,selecttheserial(COM)orUSBportonthecomputerthatthe
receiverisconnectedto.
4. ClickNext.
TheOperationSelectionscreenappears.
TheOperationslistshowsallofthesupported
operationsfortheselecteddevice.Adescriptionoftheselectedoperationisshowninthe
Descriptionfield.
5. SelectLoadGPSsoftwareandthenclickNext.
TheGPSSoftwareSelectionwindowappears.Thisscreenpromptsyoutoselectthesoftware
thatyou
wanttoinstallonthereceiver.
6. FromtheAvailableSoftwarelist,selectthelatestversionandthenclickNext.
TheSettingsReviewwindowappears.Thisscreenpromptsyoutoconnectthereceiver,
suggestsaconnectionmethodandthenliststhereceiverconfigurationandselected
operation.
7. Ifallis
correct,clickFinish.
Basedonyourselections,theSoftwareUpgradewindowappearsandshowsthestatusofthe
operation,forexample,Establishing communication with <your
receiver>. Please wait.
8. ClickOK.
TheSoftwareUpgradewindowappearsagainwithamessagethattheoperationwas
completedsuccessfully.
9. Toselectanotheroperation,clickMenu;toquit
theWinFlashutility,clickExit.
IfyouclickExit,thesystempromptsyoutoconfirm.
10. ClickOK.
Addingfrequenciesforthe450MHzinternalradiousing
theWinFlashutility
Ifyourreceiverhastheoptionalinternalradioinstalled,youcanusetheWinFlashutilitytoadd
receivingfrequenciestothedefaultlist.
Youcanalsousethewebinterfacetoaddandmanagereceiver450MHzfrequencies
.
Ifyoupurchaseatransmitupgrade(afterinitialpurchase),thebroadcastfrequenciesmustbe
programmedusinga.setfileobtainedfromaTrimbleserviceprovider.
1. StarttheWinFlashutility.TheDeviceConfigurationscreenappears.
2. FromtheDevicetypelist,selectthereceiver.
