TrimbleR10ReceiverWebHelp
3. FromthePCserialportfield,selecttheserial(COM)portorUSBportonthecomputerth atthe
receiverisconnectedto.
4. ClickNext.
TheOperationSelectionscreenappears.TheOperationslistshowsallofthesupported
operationsfortheselecteddevice.A
descriptionoftheselectedoperationisshowninthe
Descriptionfield.
5. SelectConfigureRadioandthenclickNext.
TheFrequencySelectiondialogappears.
6. IntheWirelessFormatgroup,selecttheappropriatechannelandwirelessmode.Thewireless
modemustbethesameforallradiosinyournetwork.
7. IntheSpecifyFrequencyfield,enterthefrequencyyou require.
8. ClickAdd.ThenewfrequencyappearsintheSelectedFrequencieslist.
{b}Note–{/b}Thefrequenciesthatyouprogrammustconformtothechannelspacingand
minimumtuningrequirementsfortheradio.Toviewthisinformation,clickRadio
Info.You
mayselecteither12.5or25kHzchannelspacing.Allradiosinyournetworkmustusethesame
channelspacing.
9. Whenyouhaveconfiguredallthefrequenciesyourequire,clickOK.
TheWinFlashutilityupdatesthereceiverradiofrequenciesandthenrestartsthereceiver.
{b}Note–{/b}
Youcanonlyconfigurereceivefrequencies.TheFCC‐approvedtransmit
frequenciesmustbespecifiedandconfiguredbyTrimble.
Configuringtheinternaltransceiver
UsetheWinFlashutilityInternalTransceiverConfigurationdialogtoconfiguretheinternal
transceiver.
{b}Tip–{/b}Toviewalistofallradioinformation,includingthecurrentconfiguration,click
RadioInfo.
1. IntheInternalTransceiverConfigurationdialog,selectthecurrentchannel.Thisdetermines
theradiooperatingfrequency.
2. Selectthewirelessmode,whichdeterminestheover‐the‐aircommunicationsparameters.
Toreducebatteryconsumptiononyourbasereceiver,setthewirelessmodeashighas
possible.Forexample,9600bps(bits
persecond)consumeshalfthepowerof4800bpsforthe
samedataformatandtimeofoperation.
{b}Note–{/b}Allradiosinthenetworkmustbeconfiguredwiththesamewirelesssetting.
3. Selecttheappropriateoperatingmode,dependingonhowyouintendtousethereceiver.For
example,select"BasewithNoRepeaters".
4. Forbasemodesonly,selectoneofthefollowingchannel‐sharingconfigurations:(thisisnot
availableforrovermodes)
