TrimbleR10ReceiverWebHelp
 IBSS/NTRIPClient‐ThetypeoftheserviceandthenameoftheBasestationorMountpointits
connectedto.
 IBSS/NTRIPServer‐ThetypeoftheserviceandthenameoftheBasestationorMountpoint
beingsenttotheNTRIPCaster
 Serial–Serial
portswillindicatethereceiverconnector,baudrate,databits,parity,andstop
bitssettingsoftheport.
 Bluetooth–TheBluetoothportnumberwillbedisplayed.
 USB–Noportwillbedisplayed.
 Radio–Noportwillbedisplayed.
Input–Thetypeofinput
thatisreceivedontheport.Thecorrectionstreaminputcurrentlybeing
usedinthepositionsolutionwillbeshowninboldtext.
Output–Thetypeofoutputthatissentontheport.
ConnectionColors–Thecoloroftheconnectionprovidesadditionalstatusinformation.
 Green–Indicates
anactiveconnectionfromanotherdeviceonthatport.
 Yellow–Indicatesaconnectionishavingproblemsorisnotfunctioningproperly.
 Red–Indicatesnoconnectionfromanotherdeviceonthatport.
 Nohighlight–Theserialportconnectionsarenothighlightedsinceitisnot
possibleto
distinguishifthereisaconnectionfromanotherdevice.
 Bold–Indicatesthatthiscorrectionstreaminputiscurrentlybeingusedfortheposition
solution.
I/OConfiguration(PortConfiguration)
Usethesesettingstosetupthereceiverinputsandoutputs.
Selectoneofthefollowingoptions:
 TCP/IP5017

 TCP/IP5018

 AddTCP/IPorUDPPort

 NTRIPClient

 NTRIPServer

 NTRIPCaster1

 NTRIPCaster2

 NTRIPCaster3

 Serial1/Lemo

 Bluetooth1

 Bluetooth2

